Netgate 1100 pfSense+ Security Gateway
RM 1.00
The Netgate® 1100 security gateway appliance with pfSense® Plus software is the ideal microdevice for the home and small office network.
Key Highlights:
- Dual-core ARM Cortex-A53 1.2 GHz CPU
- 3x 1 GbE Ethernet Ports
- 1 GB DDR4 RAM
- Up to 927 Mbps routing throughput
- Fanless, silent operation
Configure Your Device
Included with Purchase:
- 1 Year Hardware Warranty
- TAC Lite Support (24x7 zero-to-ping)
- pfSense+ Software License
- Automatic Configuration Backup Service
Product Overview
With a compact form factor, low power draw, and silent operation it can run completely unnoticed on a desktop or wall. Featuring a Dual-core ARM Cortex-A53 1.2 GHz CPU, (3) 1 GbE ports, and 1 GB of DDR4 RAM, the Netgate 1100 enables up to 927 Mbps routing and 607 Mbps of firewall throughput.
The Netgate 1100 delivers a substantial improvement in pfSense Plus firewall performance relative to its highly popular predecessor, the SG-1000. Consumer and business customers will quickly appreciate this product packs a serious punch with pfSense Plus software, world-class price-performance, elegant packaging, and an unbeatable low price.
Best For:
- Consumers & Home Users
- Remote Workers
- Small to Medium-Sized Business Networks
- Small to Medium-Sized Branch Office
- Managed Service Providers (MSP/MSSP) On-Premises Appliance
Key Benefits:
Enhanced Security
Secured with pfSense Plus software. First product equipped with Microchip® CryptoAuthentication Device.
Price-Performance Killer
5x packet processing performance gain vs. the Netgate SG-1000. 64-bit ARMv8 networking platform.
Modern Packaging
Cost-efficient, low power. Sleek, compact, and attractive case. Quiet operation with fanless design.
Low Total Cost of Ownership
No artificial limits or add-ons required. No additional usage or feature-based pricing.
Why Choose KF Legacy?
- Official Netgate Partner
- pfSense Certified Engineers
- Local Support (MY/EN)
- Professional Deployment
- Competitive Pricing
Contact:
enquiry@kflegacyresources.com
Technical Specifications
| SoC | Marvell Armada 3720LP (88F3720) dual core ARM Cortex A53 processor @ 1.2GHz |
|---|---|
| System Memory | 1 GB DDR4 RAM on board |
| Storage | 10.6 GB eMMC storage |
| Network Interfaces | 1x Marvell 88E6141 networking switch 3x GbE Ethernet (WAN/LAN/OPT) |
| USB | 1x USB 3.0 1x USB 2.0 1x Micro USB port (console) |
| Misc | Reset button, heatsink, 3 Status LED |
| Power | 12V 2A DC 5.5mm x 2.1mm x 10mm jack, center pin positive (power over USB not supported) |
| Power Consumption | 3.48W (idle) |
| Operating Temperature | 0°C (32°F) to 45°C (113°F) |
| Enclosure | Plastic 110 x 84.6 x 31.75 mm (4.33" x 3.33" x 1.25") |
| Hardware Warranty | 1 year standard with purchase |
| Certifications | CE, FCC, RoHS, UKCA, TAA |
Performance Metrics
Netgate 1100 performance tests conducted with pfSense Plus software version 22.01
L3 Forwarding
Firewall (10k ACLs)
IPsec VPN
(AES-CBC-128 + SHA1)Performance Note
Maximum Active Connections: 1 million. Performance may vary based on configuration, enabled features, and network conditions.
pfSense Plus Software Features
Router
- Policy-based routing
- Multiple IP addresses per interface
- Multiple WAN connections (with load balancing and failover)
- Complex NAT mapping (outbound and inbound)
- Concurrent IPv4 and IPv6 support
- Optional multi-node High Availability (HA) clustering
- Dynamic routing protocol support [w/pkg]
Firewall & Security
- Extensive firewall rules
- Stateful filtering & packet inspection
- Per-interface configuration
- Ethernet (layer 2) rule-based packet filtering
- IP/DNS-based filtering and blacklisting [w/pkg]
- IDS/IPS with Snort-based packet analyzer [w/pkg]
- Layer 7 application detection and blocking [w/pkg]
- Geo/country blocking, IP block lists [w/pkg]
VPN
- Site-to-site and remote access VPNs
- IPsec, OpenVPN, WireGuard®
- Split tunneling
- IPsec policy-based and route-based protocol support
- OpenVPN Data Channel Offload (DCO)
User Authentication
- User and group-based privileges
- LDAP authentication
- Automatic lockout after repeated attempts
- Optional key-based SSH access
- Traffic and bandwidth shaping
- Captive portal with user data transfer quotas
- External RADIUS authentication [w/pkg]
Configuration
- Setup wizard for initial configuration
- Encrypted automatic backup to Netgate server
- Easy configuration backup/restore
- Multi-language support
- Web-based GUI management
Monitoring & Reporting
- Customizable dashboard with widgets
- Local monitoring graphs
- Remote logging
- Network usage monitoring [w/pkg]
- Network diagnostics [w/pkg]
Support Information
- TAC Lite included with purchase
- 24x7x365 zero-to-ping support
- Access to pfSense+ online documentation
- TAC Pro and Enterprise SLA available
Warranty Information
- 1 year manufacturer's hardware warranty
- Extended warranties available
- Standard 30 day return policy
- All specifications subject to change
Additional Information
- Standard build time: 2-3 days after payment
- Not POE compatible
- Does not support mSATA or LTE cards
- Quick Start Guide included
